FAE Prime Tech PT300 Mulcher Rock Guard Kit

Fully welded, ready to bolt on, rock guard kit for the FAE PT300 mulcher with Free Shipping in the Continental US.

These rock guards utilize the OEM hardware and mounting locations on the Prime Tech PT-300.  They also incorporate two additional M16-2.0 bolt mounts into the track drive housing.  This gives the rock guards much more strength and stability.  The customer will need to drill these two holes per side on their machine.

The rock guards have a 10 degree tilt built into the design to allow track flotation and articulation without prematurely wearing the guards.  They will be shipped jig welded with FCAW-G (Dual Shield) wire welding. This is a high deposition and penetration welding method for strength and low hydrogen input to avoid cracking.  They are built from 3/8" AR400 which is much stronger and wear resistant than OEM.

The cross bolts are upgraded to 1"-8 Grade 8 hardware that retain both guards from splaying out during load.  Bolt-on extensions to cover the drive sprocket are also included.

These rock guards will give you many more operating hours on undercarriage maintenance and will significantly reduce downtime.  Designed and built to withstand the abuse of the Sierra Nevada operating conditions, by a California-based small business. Built to Survive!
